Anchor UNO B0 MCCB | 125A - 250A Range | 250AF 25kA | ATFM 3P & 4P Protection Logic
| Specification | Technical Details (3-Pole) | Technical Details (4-Pole) |
| Brand | Anchor | Anchor |
| Model Numbers | 98569, 98570, 98571, 98572 | 98573, 98574, 98575, 98576 |
| Series | UNO B0 | UNO B0 |
| Product Type | Molded Case Circuit Breakers (MCCB) | Molded Case Circuit Breakers (MCCB) |
| Frame Size | 250AF | 250AF |
| Current Ratings (In) | 125A, 160A, 200A, 250A | 125A, 160A, 200A, 250A |
| No. of Poles | 3 Pole | 4 Pole |
| Breaking Capacity | 25 kA | 25 kA |
| Release Type | ATFM (Adjustable Thermal) | ATFM (Adjustable Thermal) |
| Color Finish | White | White |
-
25kA Industrial Breaking Logic: Engineered by Anchor to safely isolate short-circuit faults up to 25kA, providing an elite safety shield for heavy-load industrial distribution networks.
-
ATFM Thermal-Magnetic Matrix: Features an "Adjustable-Thermal-Fixed-Magnetic" release system, providing users with the logic to fine-tune overload protection while maintaining fixed short-circuit response.
-
250AF High-Capacity Structural Frame: Built with a robust 250 Ampere frame size, designed to accommodate higher thermal stresses and larger cable terminations required for primary electrical hubs.
-
3-Pole and 4-Pole Configuration Shield: Available in both 3P and 4P configurations to support comprehensive isolation requirements, including neutral-line protection in complex 4-wire systems.
-
Flame-Retardant Industrial Housing: Constructed from premium white thermal-plastic molding that ensures high-impact durability and heat dissipation for stable performance in high-current environments.
