Kirloskar GMC Series Heavy-Duty Centrifugal Monobloc Pump | Three-Phase CED Anti-Rust Coated Water Pump for Cooling Towers, HVAC & Industrial Utilities

Description

Specification	Parameter
Brand	Kirloskar
Series	GMC Series
Pump Type	Surface Centrifugal Monobloc Pump
Power Range	0.75 kW to 1.10 kW (1.0 HP to 1.5 HP)
Operating Speed	~2,900 RPM (2-Pole High-Speed Motor)
Operating Voltage	Three-Phase, 300V to 440V (Wide Voltage Design), 50 Hz
Total Head Range	Up to 38 Meters
Insulation Class	Class B
Enclosure Protection	IP44 / IP55
Surface Treatment	Cathodic Electro Deposition (CED) Anti-Corrosion Coating
Impeller Material	Cast Iron / High-Grade Noryl
Casing & Motor Body	Heavy-Duty Cast Iron
Pump Shaft Material	Precision Carbon Steel
Sealing Type	Leak-Proof Mechanical Seal
Best Used For	HVAC Cooling Towers, Refrigeration, Industrial Utilities, Firefighting & Pressure Boosting

Cathodic Electro Deposition (CED) Coating: Cast iron components are treated with advanced CED coating technology, delivering 5x greater rust and corrosion protection than standard paint finishes.
Flatter Efficiency Curve & Overload Protection: Maintains peak energy efficiency across varying operational heads and safeguards motor windings from burnouts during low-head operation.
Automatic Air Release Mechanism: Integrated self-venting design automatically discharges air pockets upon startup to deliver swift, effortless priming without manual intervention.
Three-Phase Wide Voltage Range (300V–440V): Engineered with a robust winding architecture designed to operate reliably through industrial supply voltage fluctuations.
Dynamically Balanced Precision Assembly: Precision-balanced rotating components with a carbon steel shaft and mechanical seal suppress vibration, lower noise, and extend bearing service life across installations in Nepal.
