Kirloskar Jaldaksh Ultra Mini Single-Phase Monoblock Water Pump | 40m High-Head & 3000 LPH Flow with Brass Impeller & Lightweight Aluminium Body

Description

Specification	Parameter
Brand	Kirloskar
Product Series / Model	Ultra Mini Series / JALDAKSH (Bronze)
Pump Type	Surface / Monoblock Water Pump
Rated Voltage / Frequency	220V AC, 1-Phase, 50 Hz
Operating Speed	2740 RPM
Number of Stages	1 (Single-Stage)
Suction & Delivery Port Size	25 mm x 25 mm (1" x 1")
Total Head Range	6 – 40 Meters
Discharge Capacity Range	750 – 3000 LPH (Liters Per Hour)
Impeller Material	High-Grade Brass
Motor Body Material	High-Thermal-Dissipation Aluminium
Delivery Casing Material	Heavy-Duty Cast Iron
Pump Shaft Material	Carbon Steel
Gross Weight	10.0 kg
Product Dimensions	34.5 x 18.5 x 25.5 cm
Net Contents	1 Pumpset Unit, 1 Strainer
Best Used For	Multi-Story Overhead Tanks, Domestic Water Supply, Garden Sprinklers & Sump Boosting

Durable Hybrid Body Construction: Built with an extruded aluminium motor body for superior heat dissipation and a rugged cast iron delivery casing for high pressure endurance.
Corrosion-Resistant Brass Impeller: Precision-machined brass impeller prevents rust seizing, reduces frictional wear, and delivers reliable fluid movement up to 2740 RPM.
High-Lift 40-Meter Dynamic Head: Engineered to deliver a dynamic head range of 6 to 40 meters, making it ideal for multi-story overhead tank filling and residential pressure boosting.
Efficient Single-Phase Electric Drive: Operates on standard 220V / 50 Hz power to provide high-volume water displacement ranging from 750 to 3000 LPH with optimized energy use.
Compact & Lightweight 10kg Profile: Standardized with 25 x 25 mm (1" x 1") inlet and outlet ports and an included strainer for quick, space-saving plumbing installations across Nepal.
