Kirloskar KDI Series Heavy-Duty Three-Phase Centrifugal Monobloc Pump | IP55 Class F CED Anti-Rust Coated Water Pump for HVAC, Firefighting & Industrial Transfer

Description

Specification	Parameter
Brand	Kirloskar
Series	KDI Series
Pump Type	Three-Phase Surface Centrifugal Monobloc Pump
Power Range	1.5 kW to 22.0 kW (2.0 HP to 30.0 HP)
Operating Speed	~2,870 to 2,900 RPM (2-Pole High-Speed Motor)
Operating Voltage	Three-Phase, 350V to 440V (Wide Voltage Design), 50 Hz
Total Head Range	Up to 76 Meters
Discharge Capacity	Up to 39 Liters per Second (LPS)
Insulation Class	Class F
Enclosure Protection	IP55
Surface Treatment	Cathodic Electro Deposition (CED) Anti-Corrosion Coating
Impeller Material	Cast Iron / Bronze / Stainless Steel
Casing & Motor Body	Heavy-Duty Cast Iron
Pump Shaft Material	Precision Stainless Steel
Sealing Type	High-Grade Mechanical Seal
Best Used For	HVAC Systems, Cooling Towers, Firefighting, Industrial Clear-Water Transfer & Large-Scale Irrigation

Cathodic Electro Deposition (CED) Coating: Cast iron body and casing are treated with advanced CED coating technology, delivering 5x greater corrosion resistance over standard industrial paints.
Three-Phase Wide Voltage Range (350V–440V): Powered by an industrial-grade Class F insulated, IP55-rated motor built to withstand voltage fluctuations without thermal burnout.
Flatter Efficiency Curve & Overload Protection: Maintains consistent energy efficiency across varying operational heads and safeguards motor windings even during low-head operation.
Superior Mechanical Seal & Stainless Steel Shaft: Features a high-grade mechanical seal paired with a precision stainless steel shaft to ensure zero water leakage and eliminate friction losses.
Automatic Air Release & Dynamic Balancing: Precision-balanced rotating assembly suppresses mechanical vibrations, while the built-in air release system vents trapped air for swift startup priming across installations in Nepal.
