| Specification | Parameter |
| Brand | Kirloskar |
| Series | KOS Series |
| Pump Type | Heavy-Duty Centrifugal Openwell Submersible Pump |
| Power Range | 0.75 kW to 11.13 kW (1.0 HP to 15.0 HP) |
| Power Supply | Three-Phase, 200V – 440V (Wide Voltage Design) / Single-Phase Options on select models, 50 Hz |
| Operating Speed | ~2,840 to 2,900 RPM (2-Pole) |
| Motor Type | Water-Cooled (Filled with Potable Water) |
| Total Head Range | 6 to 76 Meters |
| Discharge Capacity | Up to 110 $m^3/hr$ (Up to 42 LPS) |
| Surface Treatment | Cathodic Electro Deposition (CED) Anti-Corrosion Coating |
| Body & Casing Material | Heavy-Duty Cast Iron |
| Impeller Material | Heavy-Duty Cast Iron |
| Pump Shaft Material | High-Grade Stainless Steel |
| Best Used For | Agricultural Irrigation, Open Wells, Community Water Supply, Industrial Utilities & High-Rise Buildings |
Zero-Priming Underwater Design: Operates fully submerged inside open wells, sumps, and reservoirs, eliminating foot valves, suction pipe leaks, and tedious manual priming.
Potable Water-Cooled Motor: Incorporates an eco-friendly, clean-water-filled motor design for active internal thermal regulation and prevention of winding burnouts during long duty cycles.
Cathodic Electro Deposition (CED) Coating: Cast iron components are treated with CED anti-corrosion coating to provide superior rust resistance and extended underwater durability.
Wide Voltage Three-Phase Operation (200V–440V): Engineered with a resilient wide-voltage winding structure that resists electrical surges and prevents low-voltage motor stalling.
Heavy-Duty High-Head & High-Flow Output: Delivers high volumetric discharge rates up to 110 $m^3/hr$ and total dynamic head reach up to 76 meters across demanding installations in Nepal.
