Microtek EML 5090 5.0 KVA Automatic Mainline Voltage Stabilizer | 90V–300V Wide Input Range | Whole-Home Digital Display Guard with MCB Protection
| Specification : | |
| Brand Profile | Microtek Power Technologies |
| Model Code Matrix | EML 5090 Series |
| Product Category | Heavy-Duty Automatic Mainline Voltage Stabilizers / Power Conditioners |
| Power Capacity Rating | 5.0 KVA (5000 Volt-Amperes Continuous Load Support Cap) |
| Primary Target Application | Centralized Mainline Voltage Regulation for Entire Home / Small Office |
| Operational Input Voltage Scope | Wide Tracking Range: 90V ~ 300V AC Single Phase Grid |
| Regulation Circuit Technology | Automatic Microcontrolled Core Step-Up / Step-Down Transformer Control |
| Current Surge Safety Element | Integrated Front-Panel Mechanical Miniature Circuit Breaker (MCB Protection) |
| Under-Voltage Cut-Off Point | Automatic Line Supply Tripping Engaged Below 90V Input |
| Over-Voltage Cut-Off Point | Automatic Line Supply Tripping Engaged Above 300V Input |
| Telemetry Interface Display | Seven-Segment Digital Display Frame with Manual Input/Output Press Button |
| System Operation Methodology | Fully Automatic Auto Start Operation Matrix / Zero Manual Intervention |
| Chassis Mechanical Framework | High-Ventilation Sheet Metal Bench / Heavy-Duty Floor Console Shell |
| Target Application Scope | Residential Homes, Micro Server Racks, Small Medical Labs, Corporate Offices |
-
Centralized 5.0 KVA Whole-Home Mainline Power Guard: Connects directly at the primary electrical input line to distribute stable, regulated current to all connected home appliances simultaneously.
-
Ultra-Wide 90V to 300V Input Tracking Matrix: Advanced internal transformer architecture dynamically manages extreme voltage sags and spikes, maintaining baseline safety parameters.
-
Interactive Seven-Segment Digital Display Console: High-visibility display indicates real-time grid input voltage by default, toggling to output metrics at the press of a front-panel button.
-
Integrated Heavy-Duty MCB Current Short Protection: Built-in Miniature Circuit Breaker (MCB) tracks downstream current surges, instantly breaking the circuit during overloading or spikes.
-
Intelligent Auto-Start Low & High Cut-Off Loop: Built-in safety sensors instantly cut off grid power routing if incoming voltage drops below 90V or jumps above 300V to shield electronics.
