Shiva Automatic Float Switch Series | IP68 Waterproof Liquid Level Controller with SPDT Micro-Switch, Dry-Run Protection & Counterweight Cable

Description

Specification	Parameter
Brand	Shiva
Series	Automatic Float Switch Series
Product Type	Automatic Fluid Level Controller / Float Switch
Model Variants	Standard Domestic \| Heavy-Duty Industrial \| Counterweight / Cable Float Switch
Switching Capacity	Up to 16A (Direct control for single-phase pumps up to 1.5 HP – 2.0 HP)
Operating Voltage	110V – 250V AC, 50/60 Hz
Contact Type	SPDT (Single Pole Double Throw) Micro-Switch
Operational Modes	Tank Filling (Normally Closed / NC) & Drainage/Emptying (Normally Open / NO)
Ingress Protection	IP68 (Fully Hermetically Sealed Submersible Design)
Housing Material	Impact-Resistant Polypropylene (PP) / Chemical-Resistant Polymer
Operating Temperature	0°C to 55°C (Water Temperature)
Cable Length Options	2m – 3m (Standard PVC) \| 5m – 10m (Rubberized / Counterweight Type)
Internal Mechanism	Mercury-Free Rolling Steel Ball Snap-Action Switch
Best Used For	Overhead Water Tanks, Underground Sumps, Sewage Pits & Agricultural Reservoirs across Nepal

Dual-Function Automation Logic: Supports versatile SPDT wiring for both tank filling (turns off when full to prevent overflow) and sump emptying (turns off when empty to prevent dry-running).
High 16A Switching Capacity: Directly powers single-phase water pump motors up to 1.5 HP – 2.0 HP on 110V–250V AC supply lines without requiring an external contactor.
IP68 Fully Hermetic Waterproofing: Built inside a double-sealed, non-toxic resin-filled polypropylene casing that guarantees complete moisture isolation and electrical safety underwater.
Mercury-Free Steel Ball Mechanism: Features a smooth internal rolling steel ball and heavy-duty snap-action micro-switch for reliable, eco-friendly liquid level transitions.
Flexible Cable & Counterweight Options: Available with standard PVC or heavy-duty rubberized cables from 2m to 10m with adjustable counterweights for custom level-swing setup across Nepal.
