UNV 16-Channel 1U AI Network Video Recorder with 2 SATA Bays, 4K HDMI, AcuSearch & Smart Intrusion Prevention | NVR302-16B-IQ
| Specification : | |
| Brand Profile | Uniview (UNV) |
| Model Code | NVR302-16B-IQ |
| Product Category | Enterprise 16-Channel AI Network Video Recorder (1U Chassis) |
| IP Video Input Capacity | 16 Channels |
| System Bandwidth | 160 Mbps Incoming / 128 Mbps Outgoing |
| Decoding Compression Standards | Ultra 265 / H.265 / H.264 / G.711A / G.711U |
| Maximum Recording Resolution | Up to 12 Megapixels |
| Video Display Outputs | HDMI: 4K (3840 x 2160) / VGA: 1080P (Simultaneous Output) |
| Storage Interfaces & Capacity | 2 SATA Bays / Up to 24 TB per HDD (48 TB Max Internal) |
| Smart AI Analytics Support | NVR-side SIP, UMD, Face Detection, AcuSearch, AcuTrack, and Vehicle Search |
| Network Interfaces | 2 x RJ45 10M/100M/1000M Self-Adaptive Ethernet Ports |
| Peripheral Interfaces | 2 x USB 2.0 / 1 x USB 3.0 / 16-ch IP Speaker Support / POS Support |
| Power Supply & Consumption | DC 12V, 3A / Consumption: Less than or equal to 12W (Without HDDs) |
| Chassis Dimensions & Weight | 380 mm x 315 mm x 53 mm (1U Height) / Less than or equal to 2.0 kg |
| Ideal Applications | Commercial Spaces, Retail Outlets, Educational Institutions, and Control Rooms |
-
16-Channel IP Processing & 160Mbps Incoming Bandwidth: Manages up to 16 high-definition IP camera inputs with 160 Mbps incoming and 128 Mbps outgoing bandwidth for smooth multi-channel live viewing and recording.
-
2 SATA HDD Bays Supporting Up to 48TB Storage: Features 2 SATA interfaces supporting up to 24 TB per disk (up to 48 TB total internal storage) for extended video archiving.
-
4K Ultra-HD HDMI & Simultaneous VGA Display Outputs: Equipped with a 4K HDMI output (3840 x 2160) and simultaneous VGA output for flexible control room video display.
-
NVR Smart AI Analytics (SIP, UMD & AcuSearch): Powered by NVR-side AI capabilities including Smart Intrusion Prevention (SIP), Ultra Motion Detection (UMD), Face Detection, AcuSearch, and AcuTrack target tracking.
-
Enterprise Connectivity & Low-Power 1U Build: Offers dual Gigabit Ethernet ports, multiple USB ports (2.0 and 3.0), and ultra-low power consumption (under 12W without HDDs) in a 1U rack-mountable chassis.
