UNV 7" Touch Screen Intelligent Face Recognition Access Control Terminal with 20,000 Face Capacity, IP65 Weatherproofing & Mifare Reader | Model No. OET-573B-HM-Z-R
| Specification : | |
| Brand Profile | Uniview (UNV) |
| Model Code | OET-573B-HM-Z-R |
| Product Category | 7-Inch Intelligent Face Recognition Access Control Terminal |
| Operating System & Algorithm | Linux OS / AI Deep Learning Facial Recognition |
| Facial Accuracy & Match Speed | > 99% Accuracy Rate / <= 200 ms Match Speed (1:N) |
| Face & Card Capacity | 20,000 Face Templates / 20,000 Mifare 1 IC Cards |
| Event Capacity & Storage | 20,000 Logs (With Images) / 100,000 Logs (Without Images) | 8GB Storage |
| Authentication Modes | Face Recognition (1:N), Mifare Card, PIN Password |
| Screen Display & Audio | 7.0-Inch Capacitive Touch Screen (600 x 1024) | Built-in Mic & Speaker |
| Supplemental Illumination | LED Soft Light + Infrared (IR) Light |
| Ingress Protection & Mounting | IP65 Rated (Outdoor/Indoor) | Metal Wall Mount & 86-Box Support |
| Communication Interfaces | 1x 100Mbps Ethernet Port, 1x RS485, 1x Wiegand In, 1x Wiegand Out |
| Access Control I/O | 1x Lock Interface, 1x Door Sensor, 1x Exit Button, 2x Alarm In, 1x Alarm Out |
| Power Supply & Consumption | DC 12V ± 25% / 6.74 W |
| Dimensions & Weight | 246.2 mm x 110.0 mm x 23.5 mm / 520 g |
| Ideal Applications | Enterprise Office Complexes, Industrial Parks, Smart Communities, and Commercial Buildings |
-
>99% Face Accuracy & 200ms Match Speed: Powered by deep learning AI algorithms for rapid, highly precise 1:N facial whitelist matching (<200 ms) with over 99% accuracy rate.
-
20,000 Face & 20,000 Card Capacity: Stores up to 20,000 facial templates, 20,000 Mifare 1 IC cards, and up to 100,000 event records (20,000 with image captures) supported by 8GB storage.
-
7-Inch Touch Display & LED/IR Fill Lights: Features a 7-inch capacitive touch screen (600 x 1024) with LED soft light and IR fill-in lights for low-light recognition and anti-spoofing protection.
-
IP65 Weatherproof Chassis with Built-in Audio: Rated IP65 for outdoor and indoor environments, complete with an integrated microphone, speaker, and built-in IC card reader.
-
Comprehensive Access Control Interfaces: Outfitted with 100Mbps Ethernet, RS485, Wiegand In/Out, lock relay, door sensor, exit button, and 2-In/1-Out alarm ports with metal wall/86-box mounting support.
